Foot-operated Impulse Poly Sealer Sealing Machine PFS-800
Supply Foot-operated Impulse Poly Sealer PFS-800 Foot Type Heating 32 Inches / 800 mm / 80 cm Wide Plastic Layflat Tubing Sealing Machine From Zhejiang Tianyu Industry Co., Ltd.Supplier Factory Manufacturer In China. Foot-operated Impulse Poly Sealer PFS-Series Foot Type Heating Plastic Layflat Tubing Sealing Machine is activated by a foot pedal, both hands are free to handle package and product. Ideal for a variety of light and medium-duty bag-sealing tasks.
The sealing process is simple: Place poly bag between seal bars, depress the pedal for a few seconds and then release. The seal process ends automatically once the preset seal time is reached.
Foot-operated Impulse Poly Sealer PFS-Series Foot Type Heating Plastic Layflat Tubing Sealing Machine is used for sealing open ends of bags by applying pressure to a foot pedal. With the ease of use, the Heat Sealer is perfect for larger or faster moving packaging stations for improved efficiency. This sealer can be used with a plastic layflat tubing.
Foot-operated Impulse Poly Sealer PFS-800 Foot Type Heating 32 Inches / 800 mm / 80 cm Wide Plastic Layflat Tubing Sealing Machine Features:
Maximum sealing length: 800 mm / 32 Inches / 80 cmMaximum bag sealing thickness: 0.8 mm X 2
Sealing Width 3 mm
Heat Time: 0.2 -2.5s
Can Make OEM Products
Foot pedal for improved efficiency.
Various sizes available on request.
Foot Impulse Sealing Machine is a high-grade sealer that is absolutely moisture resistant.
We offer premium sealers at economical costs.
Our Foot Operated Impulse Sealer is one of the most demanded products and has been greatly appreciated by our esteemed clientele for its efficient performance.
The machine is accompanied by a transformer and a digital timer for its robust working.
Seals pouches made of PP/LDPE/PE/HM/HDPE i.e all heat sealable plastic material
The machine comes with a robust transformer and a digital timer giving it a long-lasting effect
The machine also involves a robust base and pedal enabling the working capacity of the machine.
Foot-operated Impulse Poly Sealer PFS-800 Foot Type Heating 32 Inches / 800 mm / 80 cm Wide Plastic Layflat Tubing Sealing Machine Specification:
Model:PFS-800
Maximum sealing length: 800 mm / 32 Inches / 80 cm
Maximum bag sealing thickness: 0.8 mm X 2
Sealing Width 3 mm
Heating time: 0.2-2.5s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8 mm
Voltage: AC220V50HZ or AC110V/60HZ
Pulse power: 1800 W
Welding time: Infinitely Adjustable
External Dimensions (LXWXH) (mm): 855X570X880 mm
Net Weight:29Kg
Material: Die-cast Aluminium Alloy
Foot-operated Impulse Poly Sealer PFS-Series Foot Type Heating Plastic Layflat Tubing Sealing Machine is made up of an Aluminum casting body that is efficiently powder coated to prevent any sort of rust to sit on the machine body. The machines Base and Pedal is made up of CI Casting which is also duly powder coated to enable solid functioning.
Foot-operated Impulse Poly Sealer PFS-800 Foot Type Heating 32 Inches / 800 mm / 80 cm Wide Plastic Layflat Tubing Sealing Machine Package List:
1 X PFS-800 Foot-operated Impulse Poly Sealer
2 X Extra Sealing Elements
2 X Extra Tteflon Sheets
Model:PFS-800
Maximum sealing length: 800 mm / 32 Inches / 80 cm
Maximum bag sealing thickness: 0.8 mm X 2
Sealing Width 3 mm
Heating time: 0.2-2.5s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8 mm
Voltage: AC220V50HZ or AC110V/60HZ
Pulse power: 1800 W
Welding time: Infinitely Adjustable
External Dimensions (LXWXH) (mm): 855X570X880 mm
Net Weight:29Kg
Material: Die-cast Aluminium Alloy
Foot-operated Impulse Poly Sealer PFS-Series Foot Type Heating Plastic Layflat Tubing Sealing Machine is made up of an Aluminum casting body that is efficiently powder coated to prevent any sort of rust to sit on the machine body. The machines Base and Pedal is made up of CI Casting which is also duly powder coated to enable solid functioning.
Foot-operated Impulse Poly Sealer PFS-800 Foot Type Heating 32 Inches / 800 mm / 80 cm Wide Plastic Layflat Tubing Sealing Machine Package List:
1 X PFS-800 Foot-operated Impulse Poly Sealer
2 X Extra Sealing Elements
2 X Extra Tteflon Sheets
1 X English User Manual
1 X Bag of Spare Parts
1 PCS/CTN
Carton Size:800X530X250 mm
Net Weight:29Kg
HS CODE:8422303090
Foot-operated Impulse Poly Sealer PFS-Series Foot Type Heating Plastic Layflat Tubing Sealing Machine Specification:
1 X Bag of Spare Parts
1 PCS/CTN
Carton Size:800X530X250 mm
Net Weight:29Kg
HS CODE:8422303090
Foot-operated Impulse Poly Sealer PFS-Series Foot Type Heating Plastic Layflat Tubing Sealing Machine Specification:
| Model. | PFS-350 | PFS-450 | PFS-650 | PFS-800 |
| Impulse Voltage | AC220V/50HZ or AC110V/60HZ | |||
| Impulse Power (W) | 1200 | 1250 | 1500 | 1800 |
| Max.Sealing Length | 14 Inch/350mm | 18 Inch/450mm | 26 Inch/650mm | 32 Inch/800cm |
| Sealing Width | 2mm/3mm/5mm/8mm/10mm | |||
| Max.sealing thickness | 0.8mm X 2 | |||
| Heat Time (sec) | 0-2.5 | |||
| Welding Time | Infinitely Adjustable | |||
| External Dimensions (L×W×H) (mm) | 450X540X880 | 550X540X880 | 700X570X880 | 855X570X880 |
| Package | 1 PCS/CTN | |||
| Carton Size(mm) | 800X530X250mm | |||
| Net Weight(Kg) | 19 | 21 | 24 | 29 |
