Plastic Tubing Sealing Machine Hand Impulse Sealer PFS-400
Plastic Tubing Sealing Machine PFS-400 Hand Make 400mm / 16 Inches / 40cm Width Plastic Bag Impulse Heat Sealer By Zhejiang Tianyu Industry Co., Ltd. Supplier Factory Manufacturer In China. Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer is reliable, hand operated machines for heat sealing of plastic bags.The Impulse Sealer only consumes power when sealing when the arm is depressed. Therefore the sealer is suitable for intermittent use and there is no startup or heating up time required. The heat element is covered with a non-stick PTFE tape to prevent any plastic from getting stuck to the element. The PTFE tape can easily be wiped clean of any residue if and when needed to help ensure a perfect seal every time. Element and PTFE tape are consumable items and will need to be replaced from time to time. A full range of spare parts is available, and we are able to assist with servicing of your Impulse Sealer.
Maximum sealing length: 400mm / 16 Inches / 40cm
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heat Time: 0.2 -2.0s
Can Make OEM Products
![Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer Wholesale Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer Wholesale Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer](/uploads/allimg/240716/1-240G6221Z5526.png)
![Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer Wholesale Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer Wholesale Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer](/uploads/allimg/240716/1-240G6221K3453.png)
Plastic Tubing Sealing Machine PFS-400 Hand Make 400mm / 16 Inches / 40cm Width Plastic Bag Impulse Heat Sealer Features:
Color:Light Blue,Green,White or Red Maximum sealing length: 400mm / 16 Inches / 40cm
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heat Time: 0.2 -2.0s
Can Make OEM Products
The precision electronic control circuit
Portable and compact size
Impulse sealing for power-saving
Adjustable timer creates perfect seals for varying bag thickness
Labour-saving design with a long handle
Low power consumption
Suitable for PE/PP bags. Different material bag need different temperature setting.
Light weight, easy to use it
Strong power but don't waste electricity
Heat time is short
It is made of Strong Plastic Body
The operation of the machine is very easy. Just put a plastic bag on the sealing platform , and then push down the handle . After 1-2 second, release the handle .The perfect seal is complete.
Plastic Tubing Sealing Machine PFS-400 Hand Make 400mm / 16 Inches / 40cm Width Plastic Bag Impulse Heat Sealer Specification:
Model: PFS-400
Color:Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 Inches / 40cm
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heating time: 0.2-2.0 s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Voltage: EU Plug, AC220V50HZ or AC110V/60HZ
Pulse power: 600 W
Welding time: infinitely adjustable
Size: 57.5X10.5X19CM
Item Weight: 2.82 Kg
Material: ABS plastic
Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer is For PE/PP/aluminium file Bags Sealing Impulse Sealing for Power-Saving Precision Electronic Control Circuit for heat Machine is simple & affordable to be used. Suitable for factories, shops and home use.
Plastic Tubing Sealing Machine PFS-400 Hand Make 400mm / 16 Inches / 40cm Width Plastic Bag Impulse Heat Sealer Package List:
1 X PFS-400 Plastic Tubing Sealing Machine
2 X 16 Inches Replacement Heating Elements
2 X 16 Inches Replacement Teflon Tapes
Model: PFS-400
Color:Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 Inches / 40cm
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heating time: 0.2-2.0 s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Voltage: EU Plug, AC220V50HZ or AC110V/60HZ
Pulse power: 600 W
Welding time: infinitely adjustable
Size: 57.5X10.5X19CM
Item Weight: 2.82 Kg
Material: ABS plastic
Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer is For PE/PP/aluminium file Bags Sealing Impulse Sealing for Power-Saving Precision Electronic Control Circuit for heat Machine is simple & affordable to be used. Suitable for factories, shops and home use.
Plastic Tubing Sealing Machine PFS-400 Hand Make 400mm / 16 Inches / 40cm Width Plastic Bag Impulse Heat Sealer Package List:
1 X PFS-400 Plastic Tubing Sealing Machine
2 X 16 Inches Replacement Heating Elements
2 X 16 Inches Replacement Teflon Tapes
1 X English User Manual
PFS-400 Plastic Tubing Sealing Machine Weight: 2.82 Kg
Color Box Size:575X105X190mm
1 PCS/Color Box
10 PCS/CTN
Carton Size:590X555X390mm
G.W/CTN:26.5Kg
PFS-400 Plastic Tubing Sealing Machine Weight: 2.82 Kg
Color Box Size:575X105X190mm
1 PCS/Color Box
10 PCS/CTN
Carton Size:590X555X390mm
G.W/CTN:26.5Kg
HS CODE:8422303090
Plastic Tubing Sealing Machine Plastic (ABS) Body PFS-Series Hand Make Plastic Bag Impulse Heat Sealer Specification:
Model. | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
Max.sealing length | 100mm (4 Inches) | 150mm (6 Inches) | 200mm (8 Inches) | 250mm (10 Inches) | 300mm (12 Inches) | 400mm (16 Inches) |
Sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
Max.sealing thickness | 0.6mm | 0.6mm | 0.6mm | 0.8mm | 0.8mm | 0.8mm |
Adjustable heating time | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-2 S |
Welding time | Infinitely Adjustable | |||||
Dimensions (LX W X H)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
Package | 1 PCS/Color Box | |||||
QTY/CTN | 20 PCS | 20 PCS | 10 PCS | 10 PCS | 10 PCS | 10 PCS |
Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
