Impulse Sealers Plastic Bag Packing Sealing Machines PFS-400
Make and Export Impulse Sealers PFS-400 Hand 400mm / 16 Inches / 40cm Wide Plastic Bag Heat Packing Sealing Machines From Zhejiang Tianyu Industry Co., Ltd. Supplier Factory Manufacturer In China.Impulse Sealers Plastic ABS Body PFS-Series Hand Plastic Bag Heat Packing Sealing Machines are Great Sealer for PE/PP Films, Bags, Bubble Wraps Etc. of Different Thicknesses Perfect for Household, Warehouse, Supermarket to Pack Candy, Stationery, Drugs Etc. Provides Needed Heat to Melt The Bag Material So as to Seal Electronic Control Circuit with a Led Indicator for Auto-Heating an Adjustable Timer with 8 Options, Meets Various Packaging Needs Tough Abs Shell with Blue Finish Replaceable Built-In Fuse with Approx.This Lightweight Heat Sealing Hand Sealer Machine Poly Free Element Plastic Sealer featuring 8 stalls temperature adjustment impulse manual hand bag sealer to meet any different materials bags. No warm up time needed, high quality electric heating wire and high temperature resistant cloth enable to heat your poly bags seals better. Upgrade Pure copper transformer make sure this tabletop heat sealer working life is double longer than normal sealing machines. Built-in fuse for safe using, easy to use and to clean, ideal for household, retail, produce, grocery stores, and industrial sealing with a certain quality superiority. Note: When seal is done, the red light will go off. Keep the handle pressed down for 2-3 seconds to get seals optimal results. Do not use wet cloth to clean the surface of heat sealing strip.
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heat Time: 0.2 -2.0s
Can Make OEM Products
Impulse Sealers PFS-400 Hand 400mm / 16 Inches / 40cm Wide Plastic Bag Heat Packing Sealing Machines Features:
Color:Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 inches / 40cmMaximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heat Time: 0.2 -2.0s
Can Make OEM Products
Suitable for PE/PP bags and so on.
Light weight, easy to use it
Strong power but don't waste electricity
Heat time is short
It is made of plastic material
More accurate with precision electronic control
Avoid the loss of product
Light weight, easy to use it
Strong power but don't waste electricity
Heat time is short
It is made of plastic material
More accurate with precision electronic control
Avoid the loss of product
Impulse Sealers PFS-400 Hand 400mm / 16 Inches / 40cm Wide Plastic Bag Heat Packing Sealing Machines Specification:
Model: PFS-400
Color :Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 inches / 40cm
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heating time: 0.2-2.0 s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Voltage: EU Plug, AC220V50HZ or AC110V/60HZ
Pulse power: 600 W
Welding time: infinitely adjustable
Size: 57.5X10.5X19CM
Item Weight: 2.82 Kg
Material: ABS plastic
SAA approval plug: US plug/EU plug/UK plug/AU plug
CE Certified
1 X PFS-400 Impulse Sealer
2 X 16 Inches Spare Heat-resistant Strip
2 X 16 Inchea Spare Heating Wire
1 X English User Manual
PFS-400 Impulse Sealer Weight: 2.82 Kg
Color Box Size:575X105X190mm
1 PCS/Color Box
10 PCS/CTN
Carton Size:590X555X390mm
G.W/CTN:26.5Kg
1. No power switch required (auto-control), link the AC power cord with socket, adjust heating time just according to the thickness of sealing-in material; put the plastic bag on the sealing-in surface and press the handle, the circuit will automatically control heating time. The power will automatically shut down when the indicator light goes out. After 1-2 seconds, release the handle to finish sealing.
2. Any damage occurs during sealing is because of over-long heating time, please spin the rotary knob anticlockwise to shorten heating time.
3. Too-short heating time will cause unstable sealing. Please spin the rotary knob clockwise to lengthen heating time
4. If the plastic bag sticks to rubber pressing board, it means the cooling time is insufficient. You must lengthen the cooling time after indicator light extinguishment. Slightly late to release the handle
5. Remain the heating time unchanged after adjustment, and no need to adjust it during continuous service.
6. Keep AC power cord always inserting on the socket, no electricity consumption when there is no sealing.
Model: PFS-400
Color :Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 inches / 40cm
Maximum bag sealing thickness: 0.4mm X 2
Sealing Width 3mm
Heating time: 0.2-2.0 s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Voltage: EU Plug, AC220V50HZ or AC110V/60HZ
Pulse power: 600 W
Welding time: infinitely adjustable
Size: 57.5X10.5X19CM
Item Weight: 2.82 Kg
Material: ABS plastic
SAA approval plug: US plug/EU plug/UK plug/AU plug
CE Certified
These machines are used to seal Sachets Pillow-type bags Pouches Dog bags Gusseted bags Suitable for sealing thermo sealable materials such as Cellophane Poly-Ethylene (LDPE & HDPE) Poly-Propylene (PP & BOPP) Poly-Vinyl chloride (PVC) Poly-Olefins (POF).
Impulse Sealers PFS-400 Hand 400mm / 16 Inches / 40cm Wide Plastic Bag Heat Packing Sealing Machines Package List:1 X PFS-400 Impulse Sealer
2 X 16 Inches Spare Heat-resistant Strip
2 X 16 Inchea Spare Heating Wire
1 X English User Manual
PFS-400 Impulse Sealer Weight: 2.82 Kg
Color Box Size:575X105X190mm
1 PCS/Color Box
10 PCS/CTN
Carton Size:590X555X390mm
G.W/CTN:26.5Kg
How to Use Impulse Sealers Plastic ABS Body PFS-Series Hand Plastic Bag Heat Packing Sealing Machines：
1. No power switch required (auto-control), link the AC power cord with socket, adjust heating time just according to the thickness of sealing-in material; put the plastic bag on the sealing-in surface and press the handle, the circuit will automatically control heating time. The power will automatically shut down when the indicator light goes out. After 1-2 seconds, release the handle to finish sealing.
2. Any damage occurs during sealing is because of over-long heating time, please spin the rotary knob anticlockwise to shorten heating time.
3. Too-short heating time will cause unstable sealing. Please spin the rotary knob clockwise to lengthen heating time
4. If the plastic bag sticks to rubber pressing board, it means the cooling time is insufficient. You must lengthen the cooling time after indicator light extinguishment. Slightly late to release the handle
5. Remain the heating time unchanged after adjustment, and no need to adjust it during continuous service.
6. Keep AC power cord always inserting on the socket, no electricity consumption when there is no sealing.
HS CODE:8422303090
Impulse Sealers Plastic ABS Body PFS-Series Hand Plastic Bag Heat Packing Sealing Machines Specification:
| Model | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Max. sealing length | 100mm/4 inches/10cm | 150mm/15cm/6 inches | 200mm/8 inches/20cm | 250mm/10 inches/25cm | 300mm/12 inches/30cm | 400mm/16 inches/40cm |
| Sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Max sealing thickness | 0.6mm | 0.6mm | 0.6mm | 0.8mm | 0.8mm | 0.8mm |
| Adjustable heating time | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-2 S |
| Dimensions (LX W X H)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 PCS/Color Box | |||||
| QTY/CTN | 20 PCS | 20 PCS | 10 PCS | 10 PCS | 10 PCS | 10 PCS |
| Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
