Impulse Heat Sealing Sealer Manual Packaging Machine PFS-150

Impulse Heat Sealing Sealer Manual Packaging Machine PFS-150

Make and Sale Impulse Heat Sealing Sealer PFS-150 Manual 150mm / 15cm / 6 inches Wide Plastic Bag Heat Packaging Machine From Zhejiang Tianyu Industry Co., Ltd. Supplier Factory Manufacturer in China.Impulse Heat Sealing Sealer Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine Can Seals polypropylene and polyethylene bags and tubing up to 6 mil thick - no warm-up required. Flat element sealer does not melt through bags and tubing,use scissors or other cutting instrument to trim bag tops and tails. Creates super strong, tamper-evident tail flap.
Impulse Heat Sealing Sealer Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine is ideal to protect products against atmospheric contaminations and moisture.They are made from food grade plastic material and are developed especially for machines that perform an external vacuum.The Vacuum pouches comprise of 2 smooth layers of polyamide(nylon)-polyethylene barrier material. 3mil is the most common thickness for vacuum pouches that meets USDA standards for food packaging. These pouches would not have a layer of fine mesh because the chamber vacuum machines evacuate air after the pouch is within the chamber.Under Packman Packaging’s food & pharmaceutical packaging’s offerings, customers can avail high quality vacuum pouches, specially designed to extend the shelf life of frozen meat, fish, poultry, cheese and medicines.


Impulse Heat Sealing Sealer PFS-150 Manual 150mm / 15cm / 6 inches Wide Plastic Bag Heat Packaging Machine Feature:


Max. Sealing Length:150mm / 15cm / 6 inches
Sealing Width: 2mm
Sealing Thickness: 0.01-0.8mm
Heat Time: 0.2 -1.5s
Can Make OEM Products
Very High-Quality International Standard
Precision electronic control circuit
Portable and compact size
ABS Plastic Case
Impulse sealing for power-saving
Adjustable timer creates perfect seals for varying bag thickness
Labor-saving design with long handle


Impulse Heat Sealing Sealer PFS-150 Manual 150mm / 15cm / 6 inches Wide Plastic Bag Heat Packaging Machine Specifications:


Model: PFS-150
Color:Gray,Black,Blue,White
Max.Sealing Length: 150mm / 15cm / 6 inches
Sealing Width: 2mm
Sealing Thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Heating Time:0.2-1.5S
Source: AC110V / 50Hz or AC220V/60Hz
Power: 220W
Dimensions: 295X95X180mm (L X W X H)
Weight: 1.24 Kg
Suitable for: PE/PP Bags
Plug Type: US Standard
Impulse Heat Sealing Sealer Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine is not continuously heated; heat is only generated only when the jaw is closed and current flows. When the bag is placed in the impulse heat sealer, the jaw is closed and pressure maintained for the time of the seal (while the light is on). Then pressure is held for about 2 seconds to allow the seal to cool. This means that ther is no heat up time and no power is consumed when the impulse heat sealer is not in use.



Impulse Heat Sealing Sealer PFS-150 Manual 150mm / 15cm / 6 inches Wide Plastic Bag Heat Packaging Machine Package Includes:



1 X PFS-150 Impulse Heat Sealing Sealer
2 X 150mm Long Extra Heating Wires
2 X 150mm Long Extra High Temperature Clothes
1 X English User Manual
PFS-150 Impulse Heat Sealing Sealer Weight: 1.24 Kg
1 PCS/Color Box
Color Box Size:29.5X9.5X18cm
20 PCS/CTN
Carton Size:52.5X29.5X65.5cm
G.W/CTN:25.84 Kg



HS CODE:8422303090
Impulse Heat Sealing Sealer Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine Specification:




Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer Make and Sale Impulse Heat Sealing Sealer Plastic Body PFS-Series Manual Plastic Bag Heat Packaging Machine Specification
Model  PFS-100 PFS-150 PFS-200 PFS-250 PFS-300 PFS-400
Impulse voltage AC220V/50HZ or AC110V/60HZ
Impulse power 150W 220W 300W 350W 400W 600W
Max. sealing length 100mm/4 inches/10cm 150mm/15cm/6 inches 200mm/8 inches/20cm 250mm/10 inches/25cm 300mm/12 inches/30cm 400mm/16 inches/40cm
Sealing width 2mm 2mm 2mm 2mm 2mm 3mm
Max sealing thickness 0.6mm 0.6mm 0.6mm 0.8mm 0.8mm 0.8mm
Adjustable heating time 0.2-1.5 S 0.2-1.5 S 0.2-1.5 S 0.2-1.5 S 0.2-1.5 S 0.2-2 S
Dimensions (LX W X H)mm 245X95X170 295X95X180 330X100X172 380X102X183 430X102X175 575X105X190
Weight 1.06KGS 1.24KGS 1.26KGS 1.58KGS 1.68KGS 2.82KGS
Package 1 PCS/Color Box
QTY/CTN 20 PCS 20 PCS 10 PCS 10 PCS 10 PCS 10 PCS
Carton Size(mm) 490X255X640 525X295X655 510X345X360 535X395X360 525X445X360 590X555X390
G.W/CTN(Kg) 23 25.84 13.38 16.4 17.78 26.5
QTY(sets)/20'GP 7000 5500 4450 3700 3350 2200
QTY(sets)/40'GP 14500 11500 9200 7650 6900 4550
QTY(sets)/40'HQ 17000 13400 10800 8950 8100 5350
