Impulse Sealer 10 Inches Manual Heat Sealing Machine PFS-250
Make and Sale Hand Impulse Flat wire Sealer PFS-250 Manual Make 250mm / 10 inches / 25cm Wide Plastic Bag Film Heat Sealing Machine By Zhejiang Tianyu Industry Co., Ltd. Supplier Factory Manufacturer In China.Hand Impulse Flat wire Sealer ABS Plastic Shell PFS-Series Manual Make Plastic Bag Film Heat Sealing Machine can be used with many different materials including polyethylene, polypropylene, co-extruded films, and more. A flat wire sealer produces wider seals than round wire sealers. Wider seals can be used with heavier products and thicker materials up to an 8 mil thickness. All flat wire sealers are made for making multiple seals daily. With proper maintenance, flat wire sealers will last years.
As operators close the top sealing arm, an impulse of heat is sent to heat the material being sealed. Once the seal light shuts off, the sealing arm can be raised and the material removed. After making the first seal, attempt to pull the seal seam apart. If the seal easily pulls apart the seal time should be increased until the sealed seam holds.
Heat Time: 0.2 -1.5s
Max Thickness for seal: 0.8mm (Max 6 Mil for PE, max 4 Mil for PP)
Can Make OEM Products
Plastic Bag Sealing Machine An adjustable timer with 8 options, meets various packaging needs.
Sealing Machine Work on Polyethylene, Polypropylene & Polyolefine Compounds plastic film.Can be easily used to package a variety of candy, food, general merchandise, stationery, and pharmaceuticals etc.
Sealer Machine Hand Sealer for all plastic films, laminated films Aluminum film sealing Area 10 Inches.
Heat Sealing Machine Perfect for household, warehouse, supermarket to pack candy, stationery, drugs etc.
Packing Machine The PFS Series plastic film sealer is the perfect sealer for PE and PP bags(including cellophane, bubble wraps, shrink wraps and thick heavy duty bags and so on), to package various kinds of candy, foodstuff, general merchandises, stationery, medicine, local specially, electric elements ect.
Color: Light Blue,Green,White or Red
Sealing Length: 250mm / 10 Inches / 25cm
Width for seal: 2mm
Heat Time: 0.2 -1.5s
Max Thickness For Seal: 0.8mm (Max 6 Mil for PE,Max 4 Mil for PP)
Source: AC110V / 60Hz or AC220V / 50Hz
Power: 350 W
Dimensions: 38 X 10.2 X 18.3Cm (L X W X H)
Weight: 1.58 Kg
Comes With 2 Replacement Kits.
SAA approval plug: US plug/EU plug/UK plug/AU plug
CE Certified
Material: ABS Plastic Shell
Hand Impulse Flat wire Sealer ABS Plastic Shell PFS-Series Manual Make Plastic Bag Film Heat Sealing Machine creates a seal that keeps products safely and securely it in the bag. Use to package a wide variety of products. These simple yet rugged machines use a timer to regulate the seal cycle, thus assuring that all bags are sealed equally, without the need of constant operator supervision.
1 X PFS-250 Impulse Flat Wire Sealer
2 X 10 Inches Spare Teflon Sheets
1 X English Instructions
Color Box Size:38 X 10.2 X 18.3cm (L X W X H)
PFS-250 Impulse Flat Wire Sealer Weight:1.58 Kg
10 PCS/CTN
Carton Size:535X395X360mm
G.W/CTN:16.4 Kg
HS CODE:8422303090
Hand Impulse Flat Wire Sealer ABS Plastic Shell PFS-Series Manual Make Plastic Bag Film Heat Sealing Machine Specification:
| Model | PFS-100 | PFS-150 | PFS -200 | PFS -250 | PFS-300 | PFS-400 |
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Max.sealing length | 100mm | 150mm | 200mm | 250mm | 300mm | 400mm |
| Max.sealing thickness | 0.3mm | 0.3mm | 0.3mm | 0.3mm | 0.3mm | 0.3mm |
| Sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Heating time | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-2S |
| Dimensions (L x W x H) Cm | 24.5X9.5X17 | 29.5X9.5X18 | 33X10X17.2 | 38X10.2X18.3 | 43X10.2X17.5 | 57.5X10.5X19 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 Pcs/Color Box | |||||
| QTY/CTN | 20PCS | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 49X25.5X64 | 52.5X29.5X65.5 | 51X34.5X36 | 53.5X39.5X36 | 52.5X44.5X36 | 59X55.5X39 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
