Impulse Plastic Sealer Hand Operated Sealing Machine PFS-200
Manual Impulse Plastic Sealer PFS-200 Hand Operated 200 mm / 8 Inches / 20 cm Wide Sealing Machine From Zhejiang Tianyu Industry Co., Ltd.Supplier Factory Manufacturer In China.Manual Impulse Plastic Sealer Plastic (ABS) Case PFS-Series Hand Operated Sealing Machine is the most popular and economical style of heat sealer / bag sealer, using a simple scissor action to press down on the sealing arm to heat seal bags or poly tubing. An impulse sealer is sometimes referred to as an I-sealer as it seals in a straight line, when the arm is pressed down it activates the sealer to send an impluse of heat through the sealing wire which welds the plastic. The Impulse sealer has several options including a separate cutter to trim away excess plastic and automatic timers with magnetic hold downs. Impulse sealers are ideal for sealing polypropylene and polythene bags and Poly Tubing as well a most shrink film including PVC or Polyolefin. Choose from 100mm, 150mm,200mm, 250mm, 300mm, 400mm, Seal Lengths.
Manual Impulse Plastic Sealer PFS-200 Hand Operated 200 mm / 8 Inches / 20 cm Wide Sealing Machine Features:
Sealing Length: 200mm / 8 Inches / 20cm
Width for seal: 2mm
Heat Time: 0.2 -1.5s
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Can OEM Products
Manual Impulse Plastic Sealer PFS-200 Hand Operated 200 mm / 8 Inches / 20 cm Wide Sealing Machine Description:
Model: PFS-200
Color: Light Blue,Green,White or Red
Sealing Length: 200mm / 8 Inches / 20cm
Width for seal: 2mm
Heat Time: 0.2 -1.5s
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Source: AC110V / 60Hz or AC220V / 50Hz
Power: 300 W
Dimensions: 33X10X17.2cm (L X W X H)
Weight: 1.26 Kg
CE and CCC Certified
Material: Plastic ABS Shell + Aluminum Frame
Width for seal: 2mm
Heat Time: 0.2 -1.5s
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Can OEM Products
Malaysia Plug
Fast heating power saving impulse sealer machine.
Adjustable temperature, precision electric control circuit
It is practical and convenient to use
Works great with any plastic bag packaging.
For PE/PP bags used to package food products
Perfect reseal unused portions of food, keep the food in freshness
Able to close up chip bags to keep food fresh and stop being exposed to dust and bacteria.
Perfect for air tight reseal of chips, snacks, foods etc.
Widely used by shop or market, this multi-use tool
Best for collection such as all food, clothing and other articles of daily life use
Made of food grade ABS material and metal.
Clean with a dry cloth or alcohol after finish use
Keep sealing edges clean - prolong the life of the heating element.
Damage to the sealing rubber will lessen the effectiveness of the sealer.
Manual Impulse Plastic Sealer PFS-200 Hand Operated 200 mm / 8 Inches / 20 cm Wide Sealing Machine Description:
Model: PFS-200
Color: Light Blue,Green,White or Red
Sealing Length: 200mm / 8 Inches / 20cm
Width for seal: 2mm
Heat Time: 0.2 -1.5s
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Source: AC110V / 60Hz or AC220V / 50Hz
Power: 300 W
Dimensions: 33X10X17.2cm (L X W X H)
Weight: 1.26 Kg
CE and CCC Certified
Material: Plastic ABS Shell + Aluminum Frame
Manual Impulse Plastic Sealer Plastic (ABS) Case PFS-Series Hand Operated Sealing Machine melts one layer of plastic to another, creating a strong permanent seal that can only be broken by cutting or ripping it open. Make sealing poly bags a quick and easy process! Set includes the replacement heating elements.
Manual Impulse Plastic Sealer PFS-200 Hand Operated 200 mm / 8 Inches / 20 cm Wide Sealing Machine Packing List:
1 X PFS-200 Manual Impulse Plastic Sealer
2 X 200mm Sealing Elements
2 X 200mm PTFE Sheets
1 X English User Manual
Color Box Size:33X10X17.2cm
PFS-200 Plastic Bag Sealing Machine Weight:1.26 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:51X34.5X36cm
G.W/CTN:13.38Kg
Plug in the sealer.
Adjust the timer knob, appropriately for the material you are sealing.
Place material to seal on the heating element.
Close sealing arm / edge, using the operation handle.
Hold arm in place until sealing light extinguishes.
Open arm. Seal Complete.
HS CODE:8422303090
Manual Impulse Plastic Sealer Plastic (ABS) Case PFS-Series Hand Operated Sealing Machine Specifications:
2 X 200mm Sealing Elements
2 X 200mm PTFE Sheets
1 X English User Manual
Color Box Size:33X10X17.2cm
PFS-200 Plastic Bag Sealing Machine Weight:1.26 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:51X34.5X36cm
G.W/CTN:13.38Kg
How to operate Manual Impulse Plastic Sealer Plastic (ABS) Case PFS-Series Hand Operated Sealing Machine:
Plug in the sealer.
Adjust the timer knob, appropriately for the material you are sealing.
Place material to seal on the heating element.
Close sealing arm / edge, using the operation handle.
Hold arm in place until sealing light extinguishes.
Open arm. Seal Complete.
HS CODE:8422303090
Manual Impulse Plastic Sealer Plastic (ABS) Case PFS-Series Hand Operated Sealing Machine Specifications:
| Model. | AFS-100 | AFS-200 | AFS -300 | AFS -400 | AFS-500 |
| Impulse power | 250W | 300W | 400W | 500W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | ||||
| Max.sealing length | 4 Inch (100mm) | 8 Inch (200mm) | 12 Inch (300mm) | 16 Inch (400mm) | 20 Inch (500mm) |
| Sealing thickness | 0.1-0.5mm | ||||
| Sealing width | 2mm | 2mm/3mm/5mm/8mm | 3mm | 3mm | |
| Heating time | 4.2-4.5S | ||||
| Welding time | Infinitely Adjustable | ||||
| Dimensions (L x W x H) Cm | 23.5X7X17 | 32X7.5X17.3 | 44X8.5X18 | 55X9.5X18.3 | 64X10X18.5 |
| Weight | 1.3KGS | 2.06KGS | 3.5KGS | 3.7KGS | 4.5KGS |
| Package | 1 Pcs/Color Box | ||||
| QTY/CTN | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 48.5X42X33.5 | 52X35X38 | 53.5X39.5X38 | 55X45X38 | 65X56X40 |
| G.W/CTN(Kg) | 23 | 17 | 19 | 24 | 30 |
| QTY(sets)/20'GP | 8100 | 4000 | 3350 | 2900 | 2000 |
| QTY(sets)/40'GP | 16300 | 8080 | 6800 | 5850 | 4000 |
| QTY(sets)/40'HQ | 20800 | 11000 | 9600 | 8100 | 5500 |
