Impulse Industrial Sealer Table Heat Sealing Machine PFS-400

Impulse Industrial Sealer Table Heat Sealing Machine PFS-400

Make and Wholesale Impulse Industrial Sealer PFS-400 Tabletop 400mm / 16 Inches / 40cm Wide Sealing Machine From Zhejiang Tianyu Industry Co., Ltd., Supplier Factory Manufacturer In China.Impulse Industrial Sealer Plastic Body PFS-Series Tabletop Sealing Machine is a great option for lower volume applications such as the sealing of plastic bags and poly-tubing. Impulse sealers apply a brief impulse of heat to close the bag and provide a durable seal. This impulse hand sealer has a 2mm,3mm,5mm,8mm seal, ideal for sealing products that are 6 mil thick or less. It is important to understand that a heat sealer with a cutter should be used for poly-tubing. Another rule of thumb is to purchase a sealer that is 4 inches,6 inches,8 inches,10 inches,12 inches,16 inches larger than the widest bag that needs to be heat sealed. The extra inch on each side of the bag will allow a strong seal and faster operation. Impulse hand sealers create excellent air and watertight seals on plastics such as polyethylene, polyurethane, polyvinylchloride, polypropylene and other heat sealable materials. A foot sealer should be considered for moderate volume applications and a band sealer for high volume. Boatman Marking offers a wide variety of impulse sealers for a spectrum of different packaging needs.


Impulse Industrial Sealer PFS-400 Tabletop 400mm / 16 Inches / 40cm Wide Sealing Machine Features:





Color:Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 inches / 40cm
Maximum sealing thickness: 0.4mm X 2
Sealing Width: 3mm
Heat Time: 0.2 -2.0s
Can Make OEM Products
Polythene/Impulse Sealer with Simple modeling, small volume, large capacity, very convenient to use.
High-temperature glue bar, durable.
Full automatic high-temperature seal.
The operation of the
4in/6in8in/10in/12in/16in Polythene/Impulse Sealer is simple, the super-strong hand pressure seal is fresh,which can extend the storage period by 5 times.
This type of sealing machine is necessary for families, shops, restaurants, hotels, hospitals, banks, and other high-end establishments.



Impulse Industrial Sealer PFS-400 Tabletop 400mm / 16 Inches / 40cm Wide Sealing Machine Specification:


Model: PFS-400
Color :Light Blue,Green,White or Red
Maximum sealing length: 400mm / 16 inches / 40cm
Maximum sealing thickness: 0.4mm X 2
Sealing Width: 3mm
Heating time: 0.2-2.0 s
Film thickness: PE 0.06-0.2mm / PP 0.03-0.8mm
Voltage: EU Plug, AC220V50HZ or AC110V/60HZ
Pulse power: 600 W
Welding time: infinitely adjustable
Size: 57.5X10.5X19CM
Item Weight: 2.82 Kg
Material: ABS plastic
SAA approval plug: US plug/EU plug/UK plug/AU plug
CE Certified

Impulse Industrial Sealer Plastic Body PFS-Series Tabletop Sealing Machine is probably the most ubiquitous packaging machines and are used to seal bags for a great variety of industries and applications. They are affordable and easy to use, which makes them a great alternative for light-duty bag sealing applications.


Impulse Industrial Sealer PFS-400 Tabletop 400mm / 16 Inches / 40cm Wide Sealing Machine Package List:


1 X PFS-400 Impulse Industrial Sealer
2 X 16 Inches Spare Heat-resistant Strip
2 X 16 Inches Spare Heating Wire
1 X English User Manual
PFS-400 Impulse Industrial Sealer Weight: 2.82 Kg
Color Box Size:575X105X190mm
1 PCS/Color Box
10 PCS/CTN
Carton Size:590X555X390mm
G.W/CTN:26.5Kg


How To Use Impulse Industrial Sealer Plastic Body PFS-Series Tabletop Sealing Machine:


1.The Impulse Industrial Sealer Plastic Body PFS-Series Tabletop Sealing Machine does not use a power switch (automatic control). Plug the ac power cord into the socket and adjust the heating time according to the thickness of the material to be sealed. Put the plastic bag on the sealing surface, then press the handle, the circuit will automatically control the heating time. When the indicator light is off, the power supply is automatically disconnected. About 1-2 seconds later, release the handle and seal.
2.The seal of each letter is damaged when it is received. That is because the heating time is too long. Please turn the knob counterclockwise to shorten the heating time.
3.If the seal is not tight, it is because the heating time is too short. Please turn the knob clockwise to extend the heating time.
4.If the plastic bag is stuck on the rubber press plate, it indicates that the cooling time is not enough. The cooling time after the indicator light is put out must be extended. Please release the handle a little later.
5.After the heating time is adjusted, it shall remain unchanged in use, and no further adjustment shall be made in continuous use.
6.The manual pressure plastic bag sealer can insert the AC power cord into the power socket at any time, without sealing and without power consumption.



HS CODE:8422303090

Impulse Industrial Sealer Plastic Body PFS-Series Tabletop Sealing Machine Specification:



Zhejiang Tianyu industry Co., Ltd. Supplier Factory Manufacturer Make and Wholesale Impulse Industrial Sealer Plastic Body PFS-Series Tabletop Sealing Machine Specification
Model FS-400 PFS-400
Body Iron Case  Plastic ABS Shell
Power voltage AC220V/50HZ 110V/60HZ
Impulse power 600W 600W
Max.sealing length 16"/400 mm/16 inch/40 cm 16"/400 mm/16 inch/40 cm
Sealing width 3mm
Max.sealing thickness 0.8mm
Adjustable heating time 0.2-1.5 S 0.2-2 S
Dimensions (L x W x H)mm 575X105X195 575X105X190
Weight 3.26KGS 2.82KGS
QTY/CTN 10 PCS 10 PCS
Carton Size(mm) 590X570X390 590X555X390
G.W/CTN(Kg) 33.6 29.2
QTY(sets)/20'GP 2140 2200
QTY(sets)/40'GP 4430 4550
QTY(sets)/40'HQ 5190 5350
