4 Inch Impulse Heat Sealer Hand Bag Sealing Machine PFS-100
Make and Sell Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine From Zhejiang Tianyu Industry Co. Ltd. Supplier Factory Manufacturer.Impulse Heat Sealer PFS Series Hand Operated Sealing Plastic Bag Film Packaging Machine is commonly used for joining thermoplastic materials such as Polyethylene and Polyurethane that require a moderate temperature to establish an effective seal. Impulse sealing is often used to seal multi-layer, metalized, and oxygen barrier bags and pouches. Properly configured, an impulse heat sealer can join two sheets of fairly heavy thermoplastic materials. Largely determined by the material being used, heat sealing usually requires a specific combination of heat, pressure, and time between each step. One of the advantages of impulse sealing is its inherent safety. High heat is only present when the sealing jaws are closed under pressure and the sealing element is energized. This means that it is virtually impossible to become burned upon contact with the sealing jaws. While the jaws can retain a small amount of residual heat over hours of continuous use, the temperature never reaches a dangerous level. The light will turn on when the sealer is activated and will turn off once sealing is completed. Use the appropriate heat setting for your material. Heat-sealed bags make sure that your products are airtight, water-resistant, and tamper-proof.
Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine Features:
Sealing Length: 100mm / 4 Inches / 10cm
Width for seal: 2mm
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Can OEM Products
Application: PP/PE bags
Sealing Speed: 20~30bag/min.
Food and non-food applications.
Commercial and home use.
Auto LED shut-off indicator light.
Adjustable timer creates perfect seals for varying bag thickness.
Labor-saving design with long handle.
Low power consumption.
Built-in fuse for safe using.
Material: Metal & ABS
Plug: EU
CE Certified
Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine Specification:
Model: PFS-100
Color: Blue,Blue,White or Red
Sealing Length:100mm / 4 inches / 10cm
Width for seal: 2mm
Max thickness for seal: 0.2mm (Max 6 Mil for PE,Max 4 Mil For PP)
Heat Time: 0.2 -1.5s
Source: AC110V/60Hz or AC220V/50Hz
Power: 150W
Material: ABS Plastic Shell
Plug Type: EU Plug or AU Plug
Dimensions: 245 X 95 X 170mm (L X W X H)
Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine Package list:
1 X PFS-100 Impulse Heat Sealer
2 X 4 Inches Sealing Wire
2 X 4 Inches High Temperature Cloth
1 X English User Manual
PFS-100 Impulse Heat Sealer Weight:1.06 Kg
1 X Color Box
1 PCS/Color Box
Color Box Size:245X95X170mm
20 PCS/CTN
Carton Size:490X255X640mm
G.W/CTN:23Kg
Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine Features:
Width for seal: 2mm
Max thickness for seal: 0.2mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Can OEM Products
Application: PP/PE bags
Sealing Speed: 20~30bag/min.
Food and non-food applications.
Commercial and home use.
Auto LED shut-off indicator light.
Adjustable timer creates perfect seals for varying bag thickness.
Labor-saving design with long handle.
Low power consumption.
Built-in fuse for safe using.
Material: Metal & ABS
Plug: EU
CE Certified
Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine Specification:
Model: PFS-100
Color: Blue,Blue,White or Red
Sealing Length:100mm / 4 inches / 10cm
Width for seal: 2mm
Max thickness for seal: 0.2mm (Max 6 Mil for PE,Max 4 Mil For PP)
Heat Time: 0.2 -1.5s
Source: AC110V/60Hz or AC220V/50Hz
Power: 150W
Material: ABS Plastic Shell
Plug Type: EU Plug or AU Plug
Dimensions: 245 X 95 X 170mm (L X W X H)
The hand-operated impulse sealers are inexpensive and portable machines used to seal Plastic bags, polypropylene (poly bags),bubble bags, PVC, polyester, poly/cello films, humidity-proof cellophane film, aluminum foil bag,PO-film-coated EPE foam bag,kraft paper bag and teabag. They are used to seal products such as medical pouches, food and
beverage products, gift items, and office supplies
Impulse Heat Sealer PFS-100 Hand Operated Sealing 100mm / 4 inches / 10cm Long and Sealing 2mm Width Plastic Bag Film Packaging Machine Package list:
1 X PFS-100 Impulse Heat Sealer
2 X 4 Inches Sealing Wire
2 X 4 Inches High Temperature Cloth
1 X English User Manual
PFS-100 Impulse Heat Sealer Weight:1.06 Kg
1 X Color Box
1 PCS/Color Box
Color Box Size:245X95X170mm
20 PCS/CTN
Carton Size:490X255X640mm
G.W/CTN:23Kg
HS CODE:8422303090
Impulse Heat Sealer PFS Series Hand Operated Sealing Plastic Bag Film Packaging Machine Specification:
| Model No. | PFS-100 | PFS-150 | PFS -200 | PFS -250 | PFS-300 | PFS-400 |
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Max sealing length | 100mm | 150mm | 200mm | 250mm | 300mm | 400mm |
| Max sealing thickness | 0.3mm | 0.3mm | 0.3mm | 0.3mm | 0.3mm | 0.3mm |
| Max sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Heating time | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-1.5S | 0.2-2S |
| Dimensions (L x W x H) Cm | 24.5X9.5X17 | 29.5X9.5X18 | 33X10X17.2 | 38X10.2X18.3 | 43X10.2X17.5 | 57.5X10.5X19 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 Pcs/Color Box | |||||
| QTY/CTN | 20PCS | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 49X25.5X64 | 52.5X29.5X65.5 | 51X34.5X36 | 53.5X39.5X36 | 52.5X44.5X36 | 59X55.5X39 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
