Impulse Bag Sealer Adjustable Timer Sealing Machine PFS-100
Make and Supply Impulse Plastic Bag Sealer 100mm / 4 inches / 10cm Wide Adjustable Heating Timer Sealing Machine PFS-100 In Factory From China.Impulse Plastic Bag Sealer Plastic ABS Shell PFS-Series Adjustable Heating Timer Sealing Machine is a durable and efficient solution for sealing food and retail products quickly and reliably.With Up to a 15-3/4" (400mm) seal bar, it produces a 2mm 3mm or 5mm wide seal in just 0.2 to 3 seconds, ensuring freshness and reducing waste. Compatible with rolled, embossed, flat, or zipper vacuum bags up to 1/32" (0.5mm) thick, this impulse sealer works with a wide variety of packaging materials.The manual sealing machine is suitable for sealing different thicknesses of PE/PP films/bags, adjustable timer switch allows accurate control of various materials and heating needs.material and heat resistant handle, anti-rust, compact and sturdy, and durable, can handle consistent productive sealing (Includes replaceable sheet and sealing elements).No need of warm-up, just plug and use, with adjustable heating modes, ensuring consistent sealing, it heats when pressed close and automatically turns off according to set mode, safe to operate.With automatic LED indicator, there is no need to how long to apply heat, the LED light is turned on when the heating elements is operating, set heating mode and press material until the LED turns off.
Impulse Plastic Bag Sealer Plastic ABS Shell PFS-Series Adjustable Heating Timer Sealing Machine for commercial use, the Impulse Plastic Bag Sealer requires no warm-up time and features a simple dial control with an indicator light to signal when the seal is ready. Its rugged aluminum and iron construction ensures long-lasting performance in foodservice, grocery, retail, or industrial settings. Easy to operate and maintain, this countertop sealer is an essential tool for keeping products fresh and presentable.
Width for seal: 2mm
Max thickness for seal: 0.6mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Can Make OEM Products
Impulse Plastic Bag Sealer 100mm / 4 inches / 10cm Wide Adjustable Heating Timer Sealing Machine Specification:
Model:PFS-100
Colour: Blue,Blue,White or Red
Max Sealing Length:100mm / 4 inches / 10cm
Width for seal: 2mm
Max thickness for seal: 0.6mm (Max 6 Mil for PE,Max 4 Mil For PP)
Heat Time: 0.2 -1.5s
Source: AC110V/60Hz or AC220V/50Hz
Power: 150W
Material: ABS Plastic Shell
Plug Type: EU Plug or AU Plug
Dimensions: 245 X 95 X 170mm (L X W X H)
Impulse Plastic Bag Sealer 100mm / 4 inches / 10cm Wide Adjustable Heating Timer Sealing Machine Features:
Width for seal: 2mm
Max thickness for seal: 0.6mm (Max 6 Mil for PE, max 4 Mil for PP)
Heat Time: 0.2 -1.5s
Can Make OEM Products
Setting the timer:
Use a higher number for thicker material.
Use a lower number if the seal burns through the bag.
If the bag sticks to the silicon rubber just give it more cooling time.
Once you set the time the machine will remain constant.
Impulse sealer maintenance:
Be sure to always keep the sealing platform clean. Leaving residue will reduce the life of the element, teflon, and silicon rubber.
Never use moisture to clean the sealing surface.
Replace torn teflon at once, because a torn cloth will damage the element. Every time you replace the element, replace the lower and upper teflon cloth.
For best operation, use only genuine replacement parts.
Change the silicon when worn or burned.
Always unplug the machine when servicing.
Step 1:Plug the impulse sealer into an AC adapted outlet. It is important to note that the machine will only operate when it's arm is depressed, otherwise no power is consumed.
Step 2:Start by setting the sealer's timer to your desired sealing time (please check your sealer's manual for individually recommended sealing times).
Step 3:Fill your bag with your desired product and spread the open end of the bag that you'd like to seal across the impulse sealer's teflon rim. For a consistent and desirable seal make sure that the bag has none, or the least amount of ripples.
Step 4:Close and press the impulse sealer's hinged arm to activate the heater and it's timer.
Step 5: Open the impulse sealer's arm and slowly remove your bag from the sealer's rim. If the bag is sticking to the sealer's rim then you'll want to lower the heating timer.
Impulse Plastic Bag Sealer 100mm / 4 inches / 10cm Wide Adjustable Heating Timer Sealing Machine Specification:
Model:PFS-100
Colour: Blue,Blue,White or Red
Max Sealing Length:100mm / 4 inches / 10cm
Width for seal: 2mm
Max thickness for seal: 0.6mm (Max 6 Mil for PE,Max 4 Mil For PP)
Heat Time: 0.2 -1.5s
Source: AC110V/60Hz or AC220V/50Hz
Power: 150W
Material: ABS Plastic Shell
Plug Type: EU Plug or AU Plug
Dimensions: 245 X 95 X 170mm (L X W X H)
Sealing your items / products to make them look professional and beautiful. The easy-to-operate impulse bag sealer is an indispensable accessory for sealed packaging. Just plug in the wire and use it without preheating. With its cast metal structure, the sealing machine is still lightweight and portable. Adjustable time and light indicator let you know the completion time of sealing, so that the sealing process is simple and clear, for home, supermarket, kitchen, shop, coffee shop, candies store, food stall, pharmacy, small factory, etc.
Impulse Plastic Bag Sealer 100mm / 4 inches / 10cm Wide Adjustable Heating Timer Sealing Machine Package list:
1 X PFS-100 Impulse Plastic Bag Sealer
2 X Sealing Wires
2 X High Temperature Clothes
1 X English User Manual
PFS-100 Impulse Plastic Bag Sealer Weight:1.06 Kg
1 X Color Box
1 PCS/Color Box
Color Box Size:245 X 95 X 170mm
20 PCS/CTN
Carton Size:490 X 255 X 640mm
G.W/CTN:23Kg
HS CODE:8422303090
Impulse Plastic Bag Sealer Plastic ABS Shell PFS-Series Adjustable Heating Timer Sealing Machine Specification:
| Model No. | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
| voltage | AC220V/50HZ 110V/60HZ | |||||
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Max sealing length | 100mm/4 inch/10cm |
150mm/15 cm/6 inch |
200mm/8 inch/20cm | 250mm/10 inch/25cm | 300mm/12 inch/30cm | 400mm/16 inch/40cm |
| Max sealing width | 2mm | 3mm | ||||
| Max sealing thickness | 0.6mm | 0.8mm | ||||
| Adjustable heating time | 0.2-1.5s | 0.2-2s | ||||
| Dimensions (L x W x H)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
| Weight | 1.06Kgs | 1.24Kgs | 1.26Kgs | 1.58Kgs | 1.68Kgs | 2.82Kgs |
| QTY/CTN | 20 Pcs | 10 Pcs | ||||
| Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
| G.W/CTN（Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
