Manual Heat Sealing Machine Plastic Impulse Sealer AFS-200
Make and Export Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine AFS-200 Hand 200mm / 8 Inches / 20cm Wide Plastic Impulse Sealer By Zhejiang Tianyu Industry Co., Ltd.Supplier Factory Manufacturer In China.Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine Aluminum Case AFS-Series Hand Plastic Impulse Sealer Make to be both a great entry point into reliable yet affordable sealing solutions, and an industry leader in terms of standard seal features.Rather than staying with the standard 2mm string seal that most impulse sealers have adopted, we wanted something a little thicker.3mm,5mm,8mm seal width gives your products a seal whose strength you can see.With seal lengths ranging from up to 20 Inches, there are plenty of options to suit your tabletop sealing needs.
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine Aluminum Case AFS-Series Hand Plastic Impulse Sealer seal poly bags and other thermoplastic materials quickly and efficiently without any warm-up time.Depending on the model of the machine, material up to 20 Inches wide and 0.8mm total thickness can be sealed.The sealers are equipped with a plug-in electronic timer that controls the different sealing times needed for the varying thicknesses of different materials.The timer automatically beeps when the seal is done.Available in 4",8", 12",16"and 20" with a 2mm,3mm,5mm or 8mm seal width.The manufacturer's kit includes two elements and two ptfe covers.Round wire heating elements are available for cut and seal applications.There is no additional charge for the round cut wire.insert the bag between the sealing bars, then press down and release.We recommend that the user hold the sealing arm down for an additional second or two to ensure enough time for the bag to set and cool.
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine AFS-200 Hand 200mm / 8 Inches / 20cm Wide Plastic Impulse Sealer Features:
Seal Width: 2 mm / 3 mm / 5 mm / 8mm
Max.Sealing Thickness: 0.5mm X 2
Heat Time: 4.2 - 4.5s
Can Make OEM
Extra Replace Kit
8 Heating Levels
Indicator Light
Easy Operation
Replacement Parts
Wide Application
Durable construction: made with high-quality Aluminum materials to ensure long-lasting performance.Adjustable temperature control: allows for precise heat settings to accommodate different thicknesses of bags and films.
Fast and efficient sealing: seals bags in just a few seconds, saving time and improving productivity.
Easy to clean: the heating element can be easily removed for cleaning and maintenance.
Convenient usage: lightweight and portable design makes it easy to use on-the-go or in a small workspace.
Versatile compatibility: can be used with a variety of bag materials, including polyethylene and polypropylene.
Safety features: equipped with over-heat protection and a safety lock to prevent accidental activation.
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine AFS-200 Hand 200mm / 8 Inches / 20cm Wide Plastic Impulse Sealer Specifications:
Model: AFS-200
Color:Gray,Black, Blue,White
Max Sealing Length: 200mm / 8 inches / 20cm
Seal Width: 2 mm / 3 mm / 5 mm / 8 mm
Max Sealing Thickness: 0.5mm X 2
Heat Time: 4.2 - 4.5s
Weight: 2.06 kg
Dimensions: 32X7.5X17.3cm (L X W X H)
Power: 300 W
Voltage: AC110V60Hz or AC220V50Hz
SAA approval plug: US plug/EU plug/UK plug/AU plug
CE,RoHS and CCC Certified.
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine Aluminum Case AFS-Series Hand Plastic Impulse Sealer provides a fast and reliable way to seal plastic bags, poly bags, and other materials. The impulse sealing technology allows for a strong, airtight seal every time, ensuring your products stay fresh and secure during storage and transportation.
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine AFS-200 Hand 200mm / 8 Inches / 20cm Wide Plastic Impulse Sealer Package Includes:
1 X AFS-200 Heat Sealing Machine
2 X 200mm Long Replacement Elements
2 X 200mm Long Replacement Teflon Tapes
1 X English Product Manual
AFS-200 Heat Sealing Machine Weight: 2.06 kg
AFS-200 Heat Sealing Machine Weight: 2.06 kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:520X350X380mm
G.W/CTN:23Kg
HS CODE:8422303090
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine Aluminum Case AFS-Series Hand Plastic Impulse Sealer Specifications:
HS CODE:8422303090
Manual Poly Tubing and Plastic Bag Film Heat Sealing Machine Aluminum Case AFS-Series Hand Plastic Impulse Sealer Specifications:
| Model. | AFS-100 | AFS-200 | AFS -300 | AFS -400 | AFS-500 |
| Impulse power | 250W | 300W | 400W | 500W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | ||||
| Max.sealing length | 4 Inches (100mm) |
8 Inches (200mm) |
12 Inches (300mm) |
16 Inches (400mm) |
20 Inches (500mm) |
| Max.sealing thickness | 0.5mm X 2 | ||||
| Sealing width | 2mm | 2mm / 3mm / 5mm / 8mm | 3mm | 3mm | |
| Heating time | 4.2-4.5S | ||||
| Dimensions (L x W x H) Cm | 23.5X7X17 | 32X7.5X17.3 | 44X8.5X18 | 55X9.5X18.3 | 64X10X18.5 |
| Weight | 1.3KGS | 2.06KGS | 3.5KGS | 3.7KGS | 4.5KGS |
| Package | 1 Pcs/Color Box | ||||
| QTY/CTN | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 48.5X42X33.5 | 52X35X38 | 53.5X39.5X38 | 55X45X38 | 65X56X40 |
| G.W/CTN(Kg) | 28 | 23 | 37 | 39 | 47 |
| QTY(sets)/20'GP | 8100 | 4000 | 3350 | 2900 | 2000 |
| QTY(sets)/40'GP | 16300 | 8080 | 6800 | 5850 | 4000 |
| QTY(sets)/40'HQ | 20800 | 11000 | 9600 | 8100 | 5500 |
