Manual Heat Sealer Hand Impulse Bag Sealing Machine AFS-200
Make and Sale Manual Heat Sealer 8 Inches / 200 mm / 20 cm Wide Hand Impulse Plastic Bag Sealing Machine AFS-200 In Factory From China.Manual Heat Sealer Aluminum Case AFS-Series Hand Impulse Plastic Bag Sealing Machine is widely applied to seal all kinds of plastics films, compound films and aluminium-plastic film.Manual Heat Sealer Aluminum Case AFS-Series Hand Impulse Plastic Bag Sealing Machine is perfectly suited for a wide range of applications, including foodstuff, candy, medicine, electric elements, and more. Whether you run a factory, shop, or service industry, this sealer is an ideal choice to ensure secure and professional packaging. It works seamlessly with Polyethylene (PE), Polypropylene (PP), Polyvinyl chloride (PVC), Poly flex, bubble packs, padded mailers, foils, and other thermoplastic materials.Specifically designed for PE/PP bags, this sealer provides a reliable sealing solution for these types of packaging. PE and PP bags are commonly used in various industries for their durability and versatility, and this sealer ensures a tight and secure seal for these materials.
Seal Width: 2 mm / 3 mm / 5 mm / 8mm
Max.Sealing Thickness: 0.5 mm X 2
Heat Time: 4.2 - 4.5 s
Can Make OEM
Manual Heat Sealer 8 Inches / 200 mm / 20 cm Wide Hand Impulse Plastic Bag Sealing Machine AFS-200 Features:
Seal Width: 2 mm / 3 mm / 5 mm / 8mm
Max.Sealing Thickness: 0.5 mm X 2
Heat Time: 4.2 - 4.5 s
Can Make OEM
Power Supply-Impulse sealers are available in various sizes and configurations, but they generally require an electrical power source.
Heating Element-The sealer has a heating element, often made of Nichrome wire, which heats up when the sealer is activated.
Jaws or Sealing Bar-Impulse sealers have sealing jaws or bars that come together when the sealer is engaged. The heating element is usually embedded in these jaws.
Sealing Process-When the operator places the plastic bag or material between the sealing jaws and activates the sealer, the jaws close, and the heating element generates a short burst of intense heat.
Cooling Cycle-After the heat is applied, the sealing jaws remain closed for a brief cooling cycle. This allows the plastic to solidify and form a strong, airtight seal.
The impulse sealers are commonly used in various industries for packaging purposes, such as sealing food items, medical supplies, and other products in plastic bags.They are known for their efficiency, ease of use, and ability to create reliable seals on different types of thermoplastic materials.
SAA Approval Plug: EU Plug/AU Plug
SAA Approval Plug: EU Plug/AU Plug
CE,RoHS and CCC Certified.
Manual Heat Sealer 8 Inches / 200 mm / 20 cm Wide Hand Impulse Plastic Bag Sealing Machine AFS-200 Specifications:
Model: AFS-200
Color:Gray,Black, Blue,White
Max Sealing Length:8 Inches / 200 mm / 20 cm
Seal Width: 2 mm / 3 mm / 5 mm / 8 mm
Max Sealing Thickness: 0.5 mm X 2
Heat Time: 4.2 - 4.5 s
Weight: 2.06 Kg
Dimensions: 32 X 7.5 X 17.3 cm (L X W X H)
Power: 300 W
Voltage: AC110V60Hz or AC220V50Hz
SAA Approval Plug:US plug/EU plug/UK plug/AU plug
CE,RoHS and CCC Certified.
Invest in our Impulse Heat Sealer to enhance your packaging operations. Its reliable sealing capability, compatibility with PE/PP bags, and power-saving design make it a valuable asset for your packaging needs. Trust in its performance to achieve professional and secure seals while improving efficiency and reducing energy consumption.
Manual Heat Sealer 8 Inches / 200 mm / 20 cm Wide Hand Impulse Plastic Bag Sealing Machine AFS-200 Package Includes:
1 X AFS-200 Manual Heat Sealer Machine
2 X Replacement Heating Elements
2 X Replacement Teflon Tapes
1 X English Product Manual
AFS-200 Manual Heat Sealer Weight: 2.06 Kg
AFS-200 Manual Heat Sealer Weight: 2.06 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:520 X 350 X 380 mm
G.W/CTN:23 Kg
HS CODE:8422303090
Manual Heat Sealer Aluminum Case AFS-Series Hand Impulse Plastic Bag Sealing Machine Specifications:
HS CODE:8422303090
Manual Heat Sealer Aluminum Case AFS-Series Hand Impulse Plastic Bag Sealing Machine Specifications:
| Model. | AFS-100 | AFS-200 | AFS -300 | AFS -400 | AFS-500 |
| Impulse power | 250W | 300W | 400W | 500W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | ||||
| Max. sealing length |
4 Inches (100mm) |
8 Inches (200mm) |
12 Inches (300mm) |
16 Inches (400mm) |
20 Inches (500mm) |
| Max.Sealing thickness | 0.8mm | ||||
| Sealing width | 2 mm | 2 mm/3 mm/5 mm/8 mm | 3 mm | 3 mm | |
| Heating time | 4.2-4.5 s | ||||
| Temperature Control | 8-level | ||||
| Dimensions (L x W x H) Cm | 23.5X7X17 | 32X7.5X17.3 | 44X8.5X18 | 55X9.5X18.3 | 64X10X18.5 |
| Weight | 1.3KGS | 2.06KGS | 3.5KGS | 3.7KGS | 4.5KGS |
| Package | 1 Pcs/Color Box | ||||
| QTY/CTN | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 48.5X42X33.5 | 52X35X38 | 53.5X39.5X38 | 55X45X38 | 65X56X40 |
| G.W/CTN(Kg) | 28 | 23 | 37 | 39 | 47 |
| QTY(sets)/20'GP | 8100 | 4000 | 3350 | 2900 | 2000 |
| QTY(sets)/40'GP | 16300 | 8080 | 6800 | 5850 | 4000 |
| QTY(sets)/40'HQ | 20800 | 11000 | 9600 | 8100 | 5500 |
