Hand Impulse Sealer Poly Tubing Heat Sealing Machine AFS-500
Export Hand Impulse Sealer Manual 20 Inches Wide Plastic Bag and Poly Tubing Heat Sealing Machine In China From Factory. Hand Impulse Sealer Manual Aluminum Body AFS-Series Plastic Bag and Poly Tubing Heat Sealing Machine is an industrial quality machine that can creat beautiful, strong sealing.Use the timer to set the heating time, and situate the pouch on the sealing area.The heating time to be set using the timer varies by the type and thickness of the machaging material.Hand Impulse Sealer with an appropriate table for general expected settings based on your work environment and model.In addition, various tables are available as option based on your environment and model.If the standard-equipped item does not match your needs, optional tables are available for your consideration.The sealing pressure may be adjusted according to bag thickness and material. Adjust the pressure by turning the pressure adjuster nut located at the center of the pressure lever. Single-Side heating type is capable of sealing materials up to 0.3mm/ 11.8mil thick in total thickness of overlapping sheets. Sealing an oxygen scavenger inside a gas-barrier material packaging can help extend a product life.
Hand Impulse Sealer Manual Aluminum Body AFS-Series Plastic Bag and Poly Tubing Heat Sealing Machine is the ideal solution for sealing small bags and tubing.Equipped with an adjustable timer and a convenient round handle for effortless operation, these sealers ensure a seamless sealing experience - no warm-up time needed. Replacement elements and PTFE strips are available directly from our Service Team should you require them.
Seal Width:3 mm
Sealing Thickness: 0.01-0.8mm
Heat Time: 4.2-4.5 s
Can Make OEM Products
Color:Gray,Black, Blue,White
Max Sealing Length:20 inches / 500 mm / 50 cm
Seal Width: 3 mm
Sealing Thickness: 0.01-0.8 mm
Heat Time: 4.2-4.5 s
Dimensions: 640 X 100 X 185 mm (L X W X H)
Weight: 4.5 Kg
Voltage: AC110V 60HZ or AC220V 50HZ
Power: 600 W
Material: Aluminum Body
Plug: US Standard
Hand Impulse Sealer Manual Aluminum Body AFS-Series Plastic Bag and Poly Tubing Heat Sealing Machine is probably the most ubiquitous packaging machines and are used to seal bags for a great variety of industries and applications. They are affordable and easy to use, which makes them a great alternative for light-duty bag sealing applications.Built-in fuse for safe use, Easy to use and to clean, ideal for household, retail, Produce, Grocery Stores, and industrial sealing with a certain quality superiority.Energy Conservation Manual Impulse Sealer，Non-Toxic, Odorless, Durable, Reinforced and Compression.
Hand Impulse Sealer Manual 20 Inches Wide Plastic Bag and Poly Tubing Heat Sealing Machine Feature:
Seal Width:3 mm
Sealing Thickness: 0.01-0.8mm
Heat Time: 4.2-4.5 s
Can Make OEM Products
Product Name: Sealing Machine
Gear position: Eight Temp Gear Adjustment
The Impulse Heat Sealer is suited for various plastic films package, like foodstuff, candy, medicine, electric elements, etc. It is mostly used in factories, shops and service industries. The sealer is most ideal for Polyethylene, Polyurethane, Polyvinylchloride, Polyflex, bubble packs, padded mailers, foils, and other thermoplastic materials.
For PE/PP Bags: The sealer can seal Polypropylene (PP) and Polyethylene (PE) type of bags.
They are mostly used for packaging.
They are mostly used for packaging.
Environmental and non-toxic, using high-quality raw materials, safe and healthy.
Adopting hollow base design, effective ventilation and heat dissipation, improve work efficiency and extend using time.
Eight-Temp adjustment for different materials and thicknesses.
Silicone beading, high-quality silicone beading, evenly sealed to ensure no sealing.
Heating components, high-quality heating strips, and durable high-temperature fabrics, effectively heat the bag for durability.
The handle is pressed down, and the user-friendly handle design makes the grip comfortable and easy to operate.
Easy to Operate
Light Weight
Heavy Duty
SAA approval plug: EU plug / AU plug
CE certified
SAA approval plug: EU plug / AU plug
CE certified
Hand Impulse Sealer Manual 20 Inches Wide Plastic Bag and Poly Tubing Heat Sealing Machine Specifications:
Color:Gray,Black, Blue,White
Max Sealing Length:20 inches / 500 mm / 50 cm
Seal Width: 3 mm
Sealing Thickness: 0.01-0.8 mm
Heat Time: 4.2-4.5 s
Dimensions: 640 X 100 X 185 mm (L X W X H)
Weight: 4.5 Kg
Voltage: AC110V 60HZ or AC220V 50HZ
Power: 600 W
Material: Aluminum Body
Plug: US Standard
Hand Impulse Sealer Manual Aluminum Body AFS-Series Plastic Bag and Poly Tubing Heat Sealing Machine is probably the most ubiquitous packaging machines and are used to seal bags for a great variety of industries and applications. They are affordable and easy to use, which makes them a great alternative for light-duty bag sealing applications.Built-in fuse for safe use, Easy to use and to clean, ideal for household, retail, Produce, Grocery Stores, and industrial sealing with a certain quality superiority.Energy Conservation Manual Impulse Sealer，Non-Toxic, Odorless, Durable, Reinforced and Compression.
Hand Impulse Sealer Manual 20 Inches Wide Plastic Bag and Poly Tubing Heat Sealing Machine Package includes:
1 X FS-500 Hand Impulse Sealer
2 X Heating Elements
2 X PTFE Strips
1 X English Product Manual
Color Box Size:640 X 100 X 185 mm
FS-500 Hand Impulse Sealer Weight: 4.5 Kg
1 PCS/Color Box
10 PCS/CTN
10 PCS/CTN
Carton Size:650 X 560 X 400 mm
G.W/CTN:30 Kg
HS CODE:8422303090
Hand Impulse Sealer Manual Aluminum Body AFS-Series Plastic Bag and Poly Tubing Heat Sealing Machine Specifications:
HS CODE:8422303090
Hand Impulse Sealer Manual Aluminum Body AFS-Series Plastic Bag and Poly Tubing Heat Sealing Machine Specifications:
| Model. | AFS-100 | AFS-200 | AFS -300 | AFS -400 | AFS-500 |
| Impulse power | 250W | 300W | 400W | 500W | 600W |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | ||||
| Max. sealing length |
4 Inches (100mm) |
8 Inches (200mm) |
12 Inches (300mm) |
16 Inches (400mm) |
20 Inches (500mm) |
| Max.Sealing thickness | 0.8mm | ||||
| Sealing width | 2 mm | 2 mm/3 mm/5 mm/8 mm | 3 mm | 3 mm | |
| Heating time | 4.2-4.5 s | ||||
| Temperature Control | 8-level | ||||
| Dimensions (L x W x H) Cm | 23.5X7X17 | 32X7.5X17.3 | 44X8.5X18 | 55X9.5X18.3 | 64X10X18.5 |
| Weight | 1.3KGS | 2.06KGS | 3.5KGS | 3.7KGS | 4.5KGS |
| Package | 1 Pcs/Color Box | ||||
| QTY/CTN | 20PCS | 10PCS | 10PCS | 10PCS | 10PCS |
| Carton Size(cm) | 48.5X42X33.5 | 52X35X38 | 53.5X39.5X38 | 55X45X38 | 65X56X40 |
| G.W/CTN(Kg) | 28 | 23 | 37 | 39 | 47 |
| QTY(sets)/20'GP | 8100 | 4000 | 3350 | 2900 | 2000 |
| QTY(sets)/40'GP | 16300 | 8080 | 6800 | 5850 | 4000 |
| QTY(sets)/40'HQ | 20800 | 11000 | 9600 | 8100 | 5500 |
