Hand Plastic Bag Heat Sealing Machine Impulse Sealer PFS-200
Supply Hand Operated Plastic Bag Heat Sealing Machine PFS-200 Manual 200 mm / 8 Inches / 20 cm Wide Impulse Sealer By Zhejiang Tianyu Industry Co., Ltd.Supplier Factory Manufacturer In China.Hand Operated Plastic Bag Heat Sealing Machine Plastic ABS Shell PFS Series Manual Impulse Sealer is a very important tool in the retail and packaging market.Quickly seals off all types of plastic bags up to 6 mils thick.The certified and ultra durable heat sealer will seal Nylon Sterilization Tubing within 1-2 seconds and then turn off automatically.Bag sealers (aka heat sealers) can be used to seal a wide variety of PVC, poly, foil, mylar and other bags.They can also be used to seal bubble pack bags and padded mailers.These sealers use impulses of electricity to quickly seal bags shut.
Hand Operated Plastic Bag Heat Sealing Machine Plastic ABS Shell PFS Series Manual Impulse Sealer can be used with both flat as an impulse sealer for welding bags as well as with a round heating elements to work as hot wire sealer by welding and cutting film at welding point especially in tubular foil application for continuous sealing, perfectly suitable in warehouses, shops,manufacturing, and catering sector, easy to us,can seal up to 0.6mm polypropylene film and up to 0.8mm polyethylene film via weld time control knob, includes replacement heating element, teflon Fabric PTFE.
Hand Operated Plastic Bag Heat Sealing Machine PFS-200 Manual 200 mm / 8 Inches / 20 cm Wide Impulse Sealer Features:
Max Sealing Length: 200 mm / 8 Inches / 20 cm
Width for seal: 2 mm
Heat Time: 0.2 -1.5s
Max thickness for seal: 0.4mm (Max 6 Mil for PE, max 4 Mil for PP)
Can OEM Products
Hand sealer machine for all plastic films, aluminium films and laminated films
Work on PE bag, foil bag and craft paper bag
Temperature adjustment for sealing different materials
Regulate the heat time duration for different thickness material
Create secure and tight seal
Long sealing element, can fit large material to be sealed
Energy saving, no power is consume under non-use condition
Good quality product
Value for money Specifications
This is a huge advantage over traditional heat sealers as impulse sealers produce less smoke and less odor.
It’s perfect for use in shipping departments, warehouses, and retail and jewelry stores.
Lightweight, portable table model.
No warm up needed and it is only hot while sealing.
Hand Operated Plastic Bag Heat Sealing Machine PFS-200 Manual 200 mm / 8 Inches / 20 cm Wide Impulse Sealer Description:
Model: PFS-200
Color: Light Blue,Green,White or Red
Max Sealing Length: 200 mm / 8 Inches / 20 cm
Width for seal: 2 mm
Heat Time: 0.2 -1.5s
Max thickness for seal: 0.4mm (Max 6 Mil for PE, max 4 Mil for PP)
Source: AC110V / 60Hz or AC220V / 50Hz
Power: 300 W
Dimensions: 33X10X17.2cm (L X W X H)
Weight: 1.26 Kg
CE and CCC Certified
Material: Plastic ABS Shell + Aluminum Frame
Hand Operated Plastic Bag Heat Sealing Machine Plastic ABS Shell PFS Series Manual Impulse Sealer features a user-friendly design that allows for effortless operation. Simply place your packaging material between the sealing bars, activate the sealing mechanism, and the machine will apply the required heat and pressure to create a secure and airtight seal.
Hand Operated Plastic Bag Heat Sealing Machine PFS-200 Manual 200 mm / 8 Inches / 20 cm Wide Impulse Sealer Packing List:
1 X PFS-200 Hand Operated Sealing Machine
2 X 8 Inches Long Extra teflon Fabric PTFE
2 X 8 Inches Long Extra Heating Element
1 X English User Manual
Color Box Size:33X10X17.2 cm
PFS-200 Hand Operated Sealing Machine Weight:1.26 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:51X34.5X36 cm
G.W/CTN:13.38Kg
2 X 8 Inches Long Extra teflon Fabric PTFE
2 X 8 Inches Long Extra Heating Element
1 X English User Manual
Color Box Size:33X10X17.2 cm
PFS-200 Hand Operated Sealing Machine Weight:1.26 Kg
1 PCS/Color Box
10 PCS/CTN
Carton Size:51X34.5X36 cm
G.W/CTN:13.38Kg
HS CODE:8422303090
Hand Operated Plastic Bag Heat Sealing Machine Plastic ABS Shell PFS Series Manual Impulse Sealer Specification:
| Model No. | PFS-100 | PFS-150 | PFS-200 | PFS-250 | PFS-300 | PFS-400 |
| Impulse voltage | AC220V/50HZ or AC110V/60HZ | |||||
| Impulse power | 150W | 220W | 300W | 350W | 400W | 600W |
| Max sealing length | 100mm/4 inches/10cm | 150mm/15cm/6 inches | 200mm/8 inches/20cm | 250mm/10 inches/25cm | 300mm/12 inches/30cm | 400mm/16 inches/40cm |
| Sealing width | 2mm | 2mm | 2mm | 2mm | 2mm | 3mm |
| Max sealing thickness | 0.6mm | 0.6mm | 0.6mm | 0.8mm | 0.8mm | 0.8mm |
| Sealing time | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-1.5 S | 0.2-2 S |
| Welding time | Infinitely Adjustable | |||||
| Dimensions (LX W X H)mm | 245X95X170 | 295X95X180 | 330X100X172 | 380X102X183 | 430X102X175 | 575X105X190 |
| Weight | 1.06KGS | 1.24KGS | 1.26KGS | 1.58KGS | 1.68KGS | 2.82KGS |
| Package | 1 PCS/Color Box | |||||
| QTY/CTN | 20 PCS | 20 PCS | 10 PCS | 10 PCS | 10 PCS | 10 PCS |
| Carton Size(mm) | 490X255X640 | 525X295X655 | 510X345X360 | 535X395X360 | 525X445X360 | 590X555X390 |
| G.W/CTN(Kg) | 23 | 25.84 | 13.38 | 16.4 | 17.78 | 26.5 |
| QTY(sets)/20'GP | 7000 | 5500 | 4450 | 3700 | 3350 | 2200 |
| QTY(sets)/40'GP | 14500 | 11500 | 9200 | 7650 | 6900 | 4550 |
| QTY(sets)/40'HQ | 17000 | 13400 | 10800 | 8950 | 8100 | 5350 |
