Foot Double-sided Heating Impulse Sealer With Cut PFS-650D
Product Details
Sale Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-650D Foot Pedal Make 26 Inches / 650 mm / 65 cm Wide Plastic Bag and Plastic Paper Sealing Machine By Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer In China.Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine is ideal for high volume poly bag and other thermoplastic sealing.The sealers are capable of sealing 15-20 bags per minute.These sealers allow you to keep both hands free for quicker and more accurate sealing.The machines are also equipped with a plug-in timer.The timer controls the sealing time needed for different materials.Once the timer is set, it will give a consistently flat seal.When the seal is done, the signal light on the timer will turn off.
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine is available in 12", 14",18", and 26" lengths with a 5mm/8mm/10mm wide seal.Depending on the the model of the sealer, materials up to 26" wide and 20 mil total thickness can be sealed.
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine is available in 12", 14",18", and 26" lengths with a 5mm/8mm/10mm wide seal.Depending on the the model of the sealer, materials up to 26" wide and 20 mil total thickness can be sealed.
Easy to Operate,Set the timer.Insert the bag between the two sealing bars and press down on the foot board. Hold down the foot board for an additional 2-3 seconds after the timer light goes off to set the seal.
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-650D Foot Pedal Make 26 Inches / 650 mm / 65 cm Wide Plastic Bag and Plastic Paper Sealing Machine Features:
Maximum sealing length:650 mm / 26 Inches / 65 cmMaximum bag sealing thickness:1 mm X 2
Sealing Width 10 mm
Heat Time: 0.2 -2.5s
Can Make OEM Products
With the help of upper jaw round wire and under jaw 10 mm flat wire, this sealer can finish cut and seal at one operation.
These sealers give the operator a secured seal while eliminating the excess material above the seal.
Distance between floor and seal is about 31 inches, if you need it taller, extension rod is always available at request.
This seal and cut impulse impulse sealer can extend its abilities with an additional accessory that allows the sealing head to be adjusted in different sealing angles. If need the accessory, please email us for quote.
Sealers work with 110 or 220 volts electricity.
No more mess, easy to clean and maintain. Great for packaging meat and fish products.
The Upper Jaw Impulse Foot Sealer has the sealing element on the upper seal jaw and the silicon rubber on the lower steel jaw.
This Upper Jaw Impulse Foot Sealer design keeps the sealing equipment above the product enabling the user to seal liquids or products with high moisture content.
Replacement parts are always available.
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-650D Foot Pedal Make 26 Inches / 650 mm / 65 cm Wide Plastic Bag and Plastic Paper Sealing Machine Specification:
Model: PFS-650D
Maximum sealing length: 650 mm / 26 Inches / 65 cm
Maximum bag sealing thickness: 1 mm X 2
Sealing Width 10 mm
Heating time: 0.2-2.5s
Voltage:AC220V50HZ or AC110V/60HZ
Pulse power:1700 W
Welding time:Infinitely Adjustable
External Dimensions (LXWXH) (mm): 700X570X880mm
Net Weight:24 Kg
Material:Die-cast Aluminium Alloy
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine is the first model designed to cut and seal in one operation. With the help of both a round wire and a flat 10 mm wire, these sealers give the operator a secured seal while eliminating the excess material above the seal.
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-650D Foot Pedal Make 26 Inches / 650 mm / 65 cm Wide Plastic Bag and Plastic Paper Sealing Machine Package List:
1 X PFS-650D Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut
2 X Heating Elements
2 X Teflon Tapes
Model: PFS-650D
Maximum sealing length: 650 mm / 26 Inches / 65 cm
Maximum bag sealing thickness: 1 mm X 2
Sealing Width 10 mm
Heating time: 0.2-2.5s
Voltage:AC220V50HZ or AC110V/60HZ
Pulse power:1700 W
Welding time:Infinitely Adjustable
External Dimensions (LXWXH) (mm): 700X570X880mm
Net Weight:24 Kg
Material:Die-cast Aluminium Alloy
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine is the first model designed to cut and seal in one operation. With the help of both a round wire and a flat 10 mm wire, these sealers give the operator a secured seal while eliminating the excess material above the seal.
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-650D Foot Pedal Make 26 Inches / 650 mm / 65 cm Wide Plastic Bag and Plastic Paper Sealing Machine Package List:
1 X PFS-650D Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut
2 X Heating Elements
2 X Teflon Tapes
1 X English User Manual
1 X Bag of Spare Parts
1 PCS/CTN
Carton Size:800X530X250mm
Net Weight:24Kg
HS CODE:8422303090
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine Specification:
1 X Bag of Spare Parts
1 PCS/CTN
Carton Size:800X530X250mm
Net Weight:24Kg
HS CODE:8422303090
Foot Operated Double-sided Heating Jaw Impulse Sealer With Cut PFS-D-Series Foot Pedal Make Plastic Bag and Plastic Paper Sealing Machine Specification:
| Model. | PFS300D | PFS-350D | PFS-450D | PFS-650D |
| Impulse Voltage | AC220V/50HZ or AC110V/60HZ | |||
| Impulse Power (W) | 900 | 1300 | 1400 | 1700 |
| Sealing Length | 12 Inch (300mm) | 14 Inch (350mm) | 18 Inch (450mm) | 26 Inch (650mm) |
| Sealing Width | 5mm/8mm/10mm | |||
| Max.sealing thickness | 1mm X 2 | |||
| Heat Time (sec) | 0-2.5 | |||
| Welding Time | Infinitely Adjustable | |||
| External Dimensions (L×W×H) (mm) | 350X540X880 | 450X540X880 | 550X540X880 | 700X570X880 |
| Package | 1 PCS/CTN | |||
| Carton Size(mm) | 800X530X250mm | |||
| Net Weight(Kg) | 17 | 19 | 21 | 24 |
