  • Foot Operated Impulse Sealer Heat Sealing Machine PFS-300D

Foot Operated Impulse Sealer Heat Sealing Machine PFS-300D

Product Details

Foot Operated Impulse Sealer PFS-300D Foot Pedal Industrial Heat 300 mm / 12 Inches / 30 cm Wide Poly Tubing Sealing Machine By Zhejiang Tianyu Industry Co., Ltd.Supplier Factory Manufacturer In China. Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine durable and dependable. They feature a tough metal body that will stand up to continued use for sealing bags and film in industrial settings. These sealers are easy to operate and maintain and require no warm-up time. Just switch on the power and you can begin sealing immediately. Pedal operation enables both of the operator’s hands to be free to position bags and pouches.
Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine is a great investment for locking in freshness and preventing staleness!  Whether used for retail, produce, grocery stores, or industrial sealing, it can handle a large workload.  Thanks to the manual foot pedal, this sealer is completely hands free, which increases the speed of sealing and packing.  This style of operation makes this unit great for high volume packaging.
Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine include an array of components and steps and require time to warm up prior to use.This impulse sealer requires no warm up;  just plug it in, set the timer, or alternatively use the manual foot pedal, and start sealing as you please!  An indicator light lets you know when a tight seal is ready.  The 5mm sealing width will give a strong seal to ensure heavier contents will not break through it.


Foot Operated Impulse Sealer PFS-300D Foot Pedal Industrial Heat 300 mm / 12 Inches / 30 cm Wide Poly Tubing Sealing Machine Features:


Maximum sealing length:300mm / 12 Inches / 30cm
Maximum bag sealing thickness:1mm X 2
Sealing Width 5mm
Heat Time: 0.2 -2.5s
Can Make OEM Products

Heating wire replacement:Loosen the screws to remove the upper plate and the Teflon cloth, take out the original heating wire then fix a new one and other components.
Micro-switch replacement:There is one micro-switch at the side of the machine head.  It must be replaced if
damaged.
The adjustment of the pressing pole for microswitch: Put 1mm thick
carton between the upper and lower pressing, check whether the microswitch is pressed by a sound of “click”.If not, please adjust the pressing pole downward
Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine let you seal PVC and polyethylene bags and other types of bags and film as well. They are used in a wide range of industries including food packaging, agriculture, pharmaceuticals, cosmetics, chemicals,clothing and retail.


Foot Operated Impulse Sealer PFS-300D Foot Pedal Industrial Heat 300 mm / 12 Inches / 30 cm Wide Poly Tubing Sealing Machine Specification:


Model: PFS-300D
Maximum sealing length: 300mm / 12 Inches / 30cm
Maximum bag sealing thickness: 1mm X 2
Sealing Width 5mm
Heating time: 0.2-2.5s
Voltage:AC220V50HZ or AC110V/60HZ
Pulse power:900 W
Welding time:Infinitely Adjustable
External Dimensions  (LXWXH) (mm): 350X540X880mm
Net Weight:17 Kg
Material:Die-cast Aluminium Alloy
Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine Is ideal for high volume poly bags and other thermoplastic sealing applications. Capable of sealing 15-20 bags per minute while allowing you to keep both hands free for quicker and more accurate sealing.



Foot Operated Impulse Sealer PFS-300D Foot Pedal Industrial Heat 300 mm / 12 Inches / 30 cm Wide Poly Tubing Sealing Machine Package List:


1 X PFS-300D Foot Operated Impulse Sealer
2 X Heating Elements
2 X Teflon Tapes
1 X English User Manual
1 X Bag of Spare Parts
1 PCS/CTN
Carton Size:800X530X250mm
Net Weight:17Kg




HS CODE:8422303090
Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine Specification:




Zhejiang Tianyu Industry Co., Ltd Supplier Factory Manufacturer Make and Wholesale Foot Operated Impulse Sealer PFS-D-Series Foot Pedal Industrial Heat Poly Tubing Sealing Machine Specification
Model.  PFS300D   PFS-350D PFS-450D PFS-650D
Impulse Voltage AC220V/50HZ or AC110V/60HZ
Impulse Power (W) 900 1300 1400 1700
Max.Sealing Length  12 Inches 14 Inches 18 Inches 26 Inches
Sealing Width 5mm / 8mm / 10mm
Max.sealing thickness 1mm X 2
Heat Time (sec) 0-2.5
Welding Time Infinitely Adjustable
External Dimensions  (L×W×H) (mm) 350X540X880 450X540X880 550X540X880 700X570X880
Package 1 PCS/CTN
Carton Size(mm)  800X530X250mm
Net Weight(Kg) 17 19 21 24
